Mean Well RT-65B AC to DC Power Supply Triple Output 5 Volt 12 Volt 12 Volt 8 Am
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| MPN | RT-65B |
| Brand | MEAN WELL |
64.6W AC/DC ENCLOSED SWITCHING POWER SUPPLY Channel 1: +5 Volts @ 5 Amps Channel 2: +12 Volts @ 2.8 Amps Channel 3: -12 Volts @ 0.5 Amp Specifications: Size (L x W x H) (inches): 5.1 x 3.9 x 1.5 Ripple and Noise (mV p-p): 80 Load Regulation: 1.0% Line Regulation: 0.5% Input: 88-264VAC @ 47-63Hz 5G Vibration Able to withstand 300VAC surge input for 5 seconds Short-circuit/overload/overvoltage protection 3-year warranty Certifications: UL/CUL/TUV/CE/CB For more 12 Volt power supplies. Detailed specifications Primary Output Voltage (VDC): 5 Output Current (A): 5 Maximum Output Power (W): 64.6 Family: RT-65 Additional Output Voltages (VDC): 12 | -12 Input Voltage (VAC): 88 to 264 Input Frequency: 47 to 63 Maximum Input Current (A): 2 Output Connector Type: Screw Terminal Block Number of Outputs: 3 Product Type: AC to DC Power Supply Agency Approvals: UL/CUL/TUV/CE/CB Efficiency (%): 77 Minimum Isolation Voltage: 3000V Operating Temperature-Min (Cel): -25 Operating Temperature-Max (Cel): 70 Length (inch): 5.1 Width (inch): 3.9 Height (inch): 1.5 Type: Auto Switching Style: Multiple Output Output Voltage (Channel 1): 5 VDC Output Current (Channel 1): 5 A Output Voltage (Channel 2): 12 VDC Output Current (Channel 2): 2.8 A Output Voltage (Channel 3): -12 VDC Output Current (Channel 3): 0.5 A
