Texscan Low Pass Filter, Fc:1.57 GHz, 8LB1520-1LRK.
Specifications
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Brand | Texscan |
| High Pass Frequency | 1.57 GHz |
| Filter Type | Low Pass |
| Low Pass Frequency | 1.57 GHz |
| MPN | 8LB1520-1LRK |
| Country/Region Of Manufacture | United States |
A low pass filter manufactured by Texscan, model number 8LB1520-1LRK, is available for your consideration. The 3-dB cutoff frequency is about 1.57 GHz. We measured the following cutoff frequencies: 3-dB cutoff frequency: 1.57 GHz 6-dB cutoff frequency: 1.58 GHz 10-dB cutoff frequency: 1.59 GHz 20-dB cutoff frequency: 1.62 GHz Measurements were made with cared-for, but ultimately uncalibrated, hobby-grade equipment so interpret the data presented here accordingly. The unit has a right-angle F-SMA connector one end and a M-SMA connector on the opposite end. A data sheet was not available for this device. This is a 50 Ohm device, tested in a 50 Ohm environment. It is used and in working condition, with signs of normal use and wear. The Texscan 8LB1520-1LRK unit, shown in the photos, is the only item included in this listing. The photos were taken on a 1 cm grid. I will combine multiple items together to reduce shipping costs and will mail one or two business days after receiving cleared payment. Questions are welcome. Thanks for stopping by!
